C6000 C Data Types TypeSize Representation char, signed char8 bitsASCII unsigned char8 bitsASCII short16 bits2s complement unsigned short16 bitsbinary int, signed int32 bits2s complement unsigned int32 bitsbinary long, signed long40 bits 2s complement unsigned long40 bits binary enum32 bits 2s complement float32 bits IEEE 32-bit double64 bits IEEE 64-bit long double64 bits IEEE 64-bit pointers32 bits binary.DSP/BIOS Configuration Tool Simplifies system design by: Automatically includes the appropriate runtime support libraries Automatically handles interrupt vectors and system reset Handles system memory configuration (builds CMD file) Generates 5 files when CDB file is saved: C file, Asm file, 2 header files and a linker command (.cmd) file More to be discussed later Simplifies system design by: Automatically includes the appropriate runtime support libraries Automatically handles interrupt vectors and system reset Handles system memory configuration (builds CMD file) Generates 5 files when CDB file is saved: C file, Asm file, 2 header files and a linker command (.cmd) file More to be discussed later.Following table lists the most common options: debug options In Chapter 4 we will examine the options which enable the compilers optimizer And, the Config Tool. OptionsDescription -mv6700Generate C67x code (C62x is default) -mv6400Generate 'C64x code -fr Directory for object/output files -fs Directory for assembly files -qQuiet mode (display less info while compiling) -gEnables src-level symbolic debugging -sInterlist C statements into assembly listing Compilers Build Options Nearly one-hundred compiler options available to tune your code's performance, size, etc.OptionsDescription -o Output file name -m Map file name -cAuto-initialize global/static C variables -圎xhaustively read libs (resolve back ref's) Linker Options -q -c -m".\Debug\lab1.map" -o".\Debug\lab1.out" -x.\Debug\lab1.out Run-time Autoinitialization By default linker options include the o option We recommend you add the m option ".\Debug\" indicates one subfolder level below the projects.pjt folder Run-time Autoinit tells compiler to initialize global/static variables before calling main().\Debug\lab1.map.Build Options -g -q -fr "c:\modem\Debug" -mv6700 Eight Categories of Compiler options The most common Compiler Options are.Hint: Create and open projects from the Project menu, not the File menu. Project Menu Access via pull-down menu or by right-clicking.pjt file in project explorer window Project Menu Hint: Create and open projects from the Project menu, not the File menu.What is a Project? Project (.PJT ) file contain: References to files: Source Libraries Linker, etc Project settings: Compiler Options DSP/BIOS Linking, etc The project menu.Code Generation.out Editor.sa Asm Optimizer.c /.cpp Compiler Asm.asm Linker.obj.
C6713 dsk code composer studio download simulator#
SIM Simulator Code Composer Studio DSKs Code Composer Studio Includes: Integrated Edit / Debug GUI Edit DSK EVM Third Party BIOS:Real-time kernel Real-time analysis DSP/BIOS Libraries DSP/BIOS Config Tool Debug Code Generation Tools Compiler Asm Opto Asm Standard Runtime Libraries.out Link XDS DSP Board CCS is Project centric.Test/Diagnose DSK hardware Verify USB emulation link Use Advanced tests to facilitate debugging Reset DSK hardware C6713 DSK Diagnostic Utility included with DSK.
